Carborundum Infrared Light Source

Carborundum Infrared Light Source



Carborundum Infrared Light Source is combinated light housing （LSH-SiN40） and power supply（LSP-T200）.It has high Luminous efficiency,
small Luminous area, collect easily;donot need water cooling and it is very convenient for application , the life time is 2000hours.

Light housing specification of LSH-SiN40
Power: ：≥40W
Spectral Range: 1-14μm（1-16μm）
f/#：f/4
Luminous size: 4mm×15mm
Volage:8V
Current :6A
Temperature of Silicon carbide: 900-1200℃
The life time of Silicon carbide:2000hours
The optical center height of optical port: 128～168mm

Steady current and volgae specification of LSP-T200

Power: 200 W
Current : 0-10 A
Volage: 0-20 V
Current stability：<0.1%
Volage stability：<0.1%
Power supply: AC220V±10%
