OMLS series Self-Centering Lens Mount

OMLS series self-centering lens mount using for holding different size of lens ,becasue of the self-centering function ,when you change another size of lens from time to time , the optical center keeps the same.

Inquiry

Download

Product Manuals

Details&Spec

Details

Features:

• High-quality materials: The main body is made of high-quality aluminium alloy, and the surface treated by black anodic oxidation.

• Self-centering function, three attach point hold the lens, the pulling spring hold the self-centering positon automatically.

• Universal: Lens size cover 5-102mm diameter

• Custom designed 2D-3D self-centering kinematic lens mount also avaliable

Selection Table:

Model	OMLS50-1	OMLS76-1	OMLS102-1
Optic Size (mm)	φ5~φ50	φ5~φ76	φ5~φ102
Max Clear Aperture A (mm)	φ46	φ72	φ100
Outline Diameter (mm)	φ70	φ102	φ140
Optic Center Height (mm)	34.5	50.5	69.5
Overall Height(mm)	88.5	121.4	159.3
Main Body Material and Treatment	aluminium alloy, surface treated by black anodic oxidation.
Overall Thickness (mm)	19	30	30
Number of Pulling Spring	2
Mounting Hole	M6
Net Weight (g)	85	198	355
